Byte 7 6 5 4 3 2 1 0 Description
Byte x+16 39 38 37 36 35 34 33 32
Byte x+17 47 46 45 44 43 42 41 40
Byte x+18 55 54 53 52 51 50 49 48
Byte x+19 63 62 61 60 59 58 57 56
Byte x+20
... x+27
Error type on channel 1: See byte x+12 to x+19: Only
available with redundancy of the IM 152-1DP
Diagnostic interrupt of input or output modules without HART
Table 7-42 Con󹪝guration from byte x+8 for diagnostic interrupt (input or output modules without
HART)
Byte 7 6 5 4 3 2 1 0 Description
Byte x+8 7B
H
: Input channel
7C
H
: Output channel
Byte x+9 Length of each channel-speci󹪝c diagnostic informa‐
tion in bits
Byte x+10 Number of channels per module
Byte x+11 Bit 0: Diagnostic event an channel 0 of the module
...
Bit 7: Diagnostic event an channel 7 of the module
Byte x+12 7 6 5 4 3 2 1 0 Error type on channel 0: Byte x+12 to x+15
The set bit (0 to 31) corresponds to the error type
number.
You can 󹪝nd additional notes on the meaning and
solution in section "Error types of the electronic mod‐
ules with PROFIBUS (Page 209)".
Bit 1: Short-circuit
Bit 6: Wire break
Bit 7: Upper measuring range exceeded
Byte x+13 15 14 13 12 11 10 9 8 Bit 8: Lower measuring range exceeded
Bit 9: Error
Byte x+14 23 22 21 20 19 18 17 16
Byte x+15 31 30 29 28 27 26 25 24 Bit 24: Actuator disconnection in safety-related oper‐
ation
Bit 26: External fault
Byte x+16
... x+19
Error type on channel 1: See Byte x+12 to x+15
Byte x+20
... x+23
Error type on channel 2: See Byte x+12 to x+15
Byte x+24
... x+27
Error type on channel 3: See Byte x+12 to x+15
Byte x+28
... x+31
Error type on channel 4: See Byte x+12 to x+15
Byte x+32
... x+35
Error type on channel 5: See Byte x+12 to x+15
Commissioning and Diagnostics
7.13 Diagnostics with STEP 7 with PROFIBUS
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 215
