Byte 7 6 5 4 3 2 1 0 Description
Byte x+36
... x+39
Error type on channel 6: See Byte x+12 to x+15
Byte x+40
... x+43
Error type on channel 7: See Byte x+12 to x+15
Diagnostic interrupt of input or output modules with HART
Table 7-43 Conguration from byte x+8 for diagnostic interrupt (input or output modules with HART)
Byte 7 6 5 4 3 2 1 0 Description
Byte x+8 65
H
: HART input or output channel
Byte x+9 1 Bit 4: Length of each channel-specic diagnostics in bits =
16 bits
Byte x+10 Number of channels per module
Byte x+11 Bit 0: Diagnostic event an channel 0 of the module
Bit 1: Diagnostic event an channel 1 of the module
Bit 2: Diagnostic event an channel 2 of the module
Bit 3: Diagnostic event an channel 3 of the module
Byte x+12 Error type on channel 0: Byte x+12 to x+13
The corresponding error type number of the channel-re‐
lated diagnostics is placed in brackets.
You can nd additional notes on the meaning and solu‐
tion in section "Error types of the electronic modules with
PROFIBUS (Page 209)".
Bit 1: HART communication error (19)
Bit 2: Short circuit, short circuit to P (1)
Bit 3: Short circuit, short circuit to ground (1)
Bit 4: Wire break (6)
Bit 5: Load voltage missing (17)
Bit 6: Overow (7)
Bit 7: Underow (8)
Byte x+13 Bit 0: HART primary variable outside of the limits (29)
Bit 1: HART non-primary variable outside of the limits (30)
Bit 2: HART analog output current saturated (4)
Bit 3: HART analog output current specied (2)
Bit 4: HART additional status available (22)
Bit 5: Reserved for HART (23)
Bit 6: HART conguration changed (27)
Bit 7: HART eld device error (26)
Byte x+14
... x+15
Error type on channel 1: See Byte x+12 to x+13
Byte x+16
... x+17
Error type on channel 2: See Byte x+12 to x+13
Byte x+18
... x+19
Error type on channel 3: See Byte x+12 to x+13
Commissioning and Diagnostics
7.13 Diagnostics with STEP 7 with PROFIBUS
ET 200iSP
216 Operating Instructions, 11/2022, A5E00247483-AK
