Siemens SIMATIC ET 200iSP User Manual

Terminal module TM‑PS‑B
Article number 6ES7193-7DB20-0AA0
Standards, approvals, certi󹪝cates
CE mark Yes
Use in hazardous areas
• ATEX marking
see ET 200iSP system
Dimensions
Width 60 mm
Height 190 mm
Depth 52 mm
Weights
Weight, approx. 230 g
Technical speci󹪝cations
Module-speci󹪝c data
Number of terminals 3
Cable cross-section 0.5 to 4 mm
2
*
Voltages, currents, electrical potentials
Insulation tested
• between supply voltages and all output voltag‐
es
DC 2500 V (for TM‑PS‑A (6ES7193-7DA10-0AA0),
TM‑PS‑B (6ES7193-7DB10-0AA0))
AC 2500 V (for TM‑PS‑A (6ES7193-7DA20-0AA0),
TM‑PS‑B (6ES7193-7DB20-0AA0))
Safety data
For TM‑PS‑A (6ES7193-7DA10-0AA0), TM‑PS‑B (6ES7193-7DB10-0AA0): U = 30 VDC max; I = 5 A max
For TM‑PS‑A (6ES7193-7DA20-0AA0), TM‑PS‑B (6ES7193-7DB20-0AA0): U = 264 VAC max; I = 5 A max
For additional information, see certi󹪝cate IECEx KEM 05.0003
https://www.iecex.com (https://www.iecex.com)
INMETRO UL-BR 12.0077
https://support.industry.siemens.com (https://support.industry.siemens.com)
* See "Wiring Rules for the ET 200iSP (Page 125)".
Approvals
ATEX II 2 G (1) GD and I M2
Ex eb [ia Ga/ib] IIC T4 Gb
Ex eb [ia IIIC Da] IIC T4 Gb
Ex eb [ia/ib] Mb
KEMA 04 ATEX 2242
0344
IECEx IECEx KEM 05.0003
Terminal modules
10.2 Terminal Modules TM-PS-A and TM-PS-B
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 253
