Siemens SIMATIC ET 200iSP User Manual

Article number 6ES7152-1AA00-0AB0
CE mark Yes
Use in hazardous areas
• ATEX marking
II2 G Ex ib IIC T4 and I M2 Ex ib I
• ATEX certi󹪝cate
04 ATEX 1243
Dimensions
Width 30 mm
Height 129 mm
Depth 136.5 mm
Weights
Weight, approx. 245 g
Technical speci󹪝cations
Module-speci󹪝c data
Bus protocol PROFIBUS RS 485-IS
Interface RS 485 (intrinsically safe)
Manufacturer's ID 8110
H
PROFIBUS addresses 1 to 125 permitted
Time stamping Yes (only for STEP 7)
• Message bu󹪜er
15 message bu󹪜ers each for 20 messages
Acyclic functions Yes
• Diagnostics
Yes
• Data records
Yes
Voltages, currents, electrical potentials
Electrical isolation
• Between the backplane bus and electronic com‐
ponents
No
• Between PROFIBUS RS 485-IS and electronics
Yes
Safety data
See EC type-examination certi󹪝cate KEMA 04 ATEX1243 Service & Support
(https://
www.siemens.com/
automation/
service&support)
INMETRO
UL-BR 12.0067
For additional informa‐
tion, see certi󹪝cate IE‐
CEx KEM 05.0005
https://www.iecex.com
(https://
www.iecex.com)
Maximum values for PROFIBUS RS 485-IS interface:
U
o
± 3.9 V
I
o
±136 mA
Network interface module
12.2 PROFIBUS interface module IM 152-1DP
ET 200iSP
286 Operating Instructions, 11/2022, A5E00247483-AK
