WARNING
Danger of explosion with wrong transceiver
The IM 152-1PN only works with intrinsically safe SFP transceiver A5E51793919. Plugging in
other transceivers may cause explosions.
Do not plug another transceiver into the IM 152-1PN.
Properties and benets of ET 200iSP
Table 2-3 Features and benets
Properties Benets
Structure
Modular structure based on 4- or 8-
channel electronic modules
• Station design optimized to contain costs
• Reduced conguration and documentation eort
• Space savings due to the ability to string modules together in any order
Extensive range of electronic modules Broad area of application
Permanent wiring due to the separa‐
tion of mechanical and electronic
components
• Prewiring possible
• Module change during operation of the station ("hot-swapping") is possible if at
least 2 electronic modules are present.
Integrated power bus Reduced eort required for wiring
Connection system
Screw or spring terminals Use of most suitable connection method
Intrinsically safe inputs and outputs
according to Ex ia IIC
Intrinsically safe sensors, actuators and HART eld devices up to Zone 0/ 20 can be
connected
Automatic coding of the electronic
modules
Quick and reliable module replacement
Large label Adequate space for clear identication
Disabling all digital outputs of a mod‐
ule by an intrinsically safe switching
signal
Control of the outputs independent of the process image
Functionality
Changing parameter settings and ex‐
pansion during operation
No restart of the station necessary
Time stamping, utter monitoring,
pulse stretching
Ecient monitoring of the inputs
Counting and frequency measure‐
ment
Options for use in technological applications
Identication and maintenance data
I&M
Unique identication/assignment of the modules used (for example, for validation,
quality assurance)
Analog value representation in S7 for‐
mat
IEEE variables Analog modules with HART support up to 4 IEEE variables in IEEE754 format
Product overview
2.1 ET 200iSP Distributed I/O Station
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 31
