4 DO DC25.5V/22mA shut down "L"
Article number 6ES7132-7GD30-0AB0
General information
Product type designation 4DQ 25.5 V DC/22 mA
Input current
Current consumption, typ. 380 mA
from load voltage L+ (without load), max. 400 mA
Power loss
Power loss, typ. 2.8 W
Address area
Address space per module
• Address space per module, max.
2 byte
Digital outputs
Type of digital output Transistor
Number of digital outputs 4; additionally 1 intrinsically-safe input for L shut‐
down
Short-circuit protection Yes
No-load voltage Uao (DC) 25.5 V
Internal resistor Ri 260 Ω
Trend key points E
• Voltage Ue (DC)
19.8 V
• Current Ie
22 mA
Output current
• for signal "1" rated value
0.022 A
Output delay with resistive load
• "0" to "1", max.
2 ms
• "1" to "0", max.
1.5 ms
Parallel switching of two outputs
• for uprating
No
Switching frequency
• with resistive load, max.
100 Hz
• with inductive load, max.
2 Hz
Cable length
• shielded, max.
500 m
• unshielded, max.
500 m
Interrupts/diagnostics/status information
Diagnostics function Yes
Alarms
• Diagnostic alarm
Yes; Parameterizable
Diagnoses
• Diagnostic information readable
Yes
• Wire-break
Yes; R > 10 kohms, I < 100 µA
• Short-circuit
Yes; R < 80 ohms
Digital electronic modules
13.2 Digital electronics module 4 DO
ET 200iSP
320 Operating Instructions, 11/2022, A5E00247483-AK
