Siemens SIMATIC ET 200iSP

Article number 6ES7132-7GD30-0AB0
Diagnostics indication LED
• Group error SF (red)
Yes
• Status indicator digital output (green)
Yes; Per channel
Ex(i) characteristics
maximum values for connecting terminals for
gas group IIC
• Uo (no-load voltage), max.
27.9 V
• Io (short-circuit current), max.
110 mA
• Po (power output), max.
764 mW
• Co (permissible external capacity), max.
81 nF; For IIC, 651 nF for IIB
• Lo (permissible external inductivity), max.
1.7 mH; For IIC, 11.5 mH for IIB
Potential separation
Potential separation digital outputs
• between the channels
No
• between the channels and backplane bus
Yes
• Between the channels and load voltage L+
Yes
Permissible potential di󹪜erence
between di󹪜erent circuits 60 V DC/30 V AC
Standards, approvals, certi󹪝cates
CE mark Yes
Highest safety class achievable in safety mode
• SIL acc. to IEC 61508
No
Dimensions
Width 30 mm
Height 129 mm
Depth 136.5 mm
Weights
Weight, approx. 255 g
Technical speci󹪝cations
Module-speci󹪝c data
Voltages, currents, electrical potentials
Electrical isolation
• Between the channels and actuator disconnection input
Yes
Status, interrupts, diagnostics
Status display
• Outputs
Green LED for each channel
Interrupts
• Hardware interrupt
No
Diagnostic functions
• Group error display
Red "SF" LED
Digital electronic modules
13.2 Digital electronics module 4 DO
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 321
