Siemens SIMATIC ET 200iSP

Article number 6ES7134-7TD00-0AB0
• for current measurement as 2-wire transduc‐
er
Yes
– Burden of 2-wire transmitter, max.
750 Ω
Errors/accuracies
Linearity error (relative to input range), (+/-) 0.015 %
Temperature error (relative to input range), (+/-) 0.005 %/K
Crosstalk between the inputs, min. -50 dB
Repeat accuracy in steady state at 25 °C (relative
to input range), (+/-)
0.01 %
Operational error limit in overall temperature
range
• Current, relative to input range, (+/-)
0.15 %
Basic error limit (operational limit at 25 °C)
• Current, relative to input range, (+/-)
0.1 %
Interference voltage suppression for f = n x (f1
+/- 1 %), f1 = interference frequency
• Series mode interference (peak value of in‐
terference < rated value of input range), min.
70 dB
Interrupts/diagnostics/status information
Alarms
• Diagnostic alarm
Yes; Parameterizable
• Limit value alarm
Yes; Parameterizable
Diagnoses
• Diagnostic information readable
Yes
• Wire-break
Yes
• Short-circuit
Yes
Diagnostics indication LED
• Group error SF (red)
Yes
Potential separation
Potential separation analog inputs
• between the channels
No
• between the channels and backplane bus
Yes
Standards, approvals, certi󹪝cates
CE mark Yes
Highest safety class achievable in safety mode
• Performance level according to ISO 13849-1
none
• SIL acc. to IEC 61508
No
Use in hazardous areas
• ATEX marking
II2 G (1) GD Ex ib[ia] IIC T4 and I M2 Ex ib[ia] I
• ATEX certi󹪝cate
04 ATEX 1244
Dimensions
Width 30 mm
Height 129 mm
Analog electronic modules
14.2 Analog electronics module 4 AI I 2WIRE HART
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 349
