Page #350 background imageLoading...
Page #350 background image
Article number 6ES7134-7TD00-0AB0
Depth 136.5 mm
Weights
Weight, approx. 230 g
Technical speci󹪝cations
Module-speci󹪝c data
Isochronous mode supported No
Voltages, currents, electrical potentials
Electrical isolation
Between channels and power bus
Yes
Formation of analog values
Integration/conversion time/resolution (per channel)
Cycle time in ms
Number of active channels per module x
basic conversion time
Resolution (including overrange)
12 bits + sign
Status, interrupts, diagnostics
Diagnostic functions
Group error display
Red "SF" LED
Monitoring for
Short-circuit
I
Load
> 25 mA
2
Wire break
I
load
< 3.6 mA
Safety information
U
o
= 27.6 V
I
o
= 91 mA
P
o
= 0.63 W
C
o
= 83 nF
L
o
= 3 mH
For additional C
o
/ L
o
combinations, see certi󹪝cate IECEx KEM 05.0006
https://www.iecex.com (https://www.iecex.com)
KEMA 04 ATEX1244
INMETRO UL-BR 12.0072
https://support.industry.siemens.com (https://support.industry.siemens.com)
Data for selecting a sensor
Input ranges (rated values) / input resistance
Current
4 to 20 mA
Permissible input current for current input (destruction
limit)
90 mA
Connection of signal generators supported
for current measurement
as 2-wire transmitter
supported
Analog electronic modules
14.2 Analog electronics module 4 AI I 2WIRE HART
ET 200iSP
350 Operating Instructions, 11/2022, A5E00247483-AK
