Siemens SIMATIC ET 200iSP User Manual

Technical speci󹪝cations
Article number 6ES7134-7SD51-0AB0
General information
Product type designation 4AI RTD
Input current
Current consumption, typ. 19 mA
from supply voltage L+, max. 22 mA
Power loss
Power loss, typ. 0.4 W
Analog inputs
Number of analog inputs 4
Cycle time (all channels) max. 320 ms; 66 ms basic conversion time x 4 channels
with interference frequency suppression 60 Hz, 80
ms basic conversion time x 4 channels with inter‐
ference frequency suppression 50 Hz
Technical unit for temperature measurement ad‐
justable
Yes
Input ranges (rated values), resistance ther‐
mometer
• Ni 100
Yes
– Input resistance (Ni 100)
2 000 kΩ
• Pt 100
Yes
– Input resistance (Pt 100)
2 000 kΩ
Input ranges (rated values), resistors
• 0 to 600 ohms
Yes; also 1 000 ohms
– Input resistance (0 to 600 ohms)
1 000 kΩ
Characteristic linearization
• parameterizable
Yes
– for resistance thermometer
Yes
Cable length
• shielded, max.
500 m
Analog value generation for the inputs
Measurement principle integrating (Sigma-Delta)
Integration and conversion time/resolution per
channel
• Resolution with overrange (bit including
sign), max.
16 bit
• Integration time, parameterizable
Yes
• Basic conversion time, including integration
time (ms)
80 ms at 50 Hz; 66 ms at 60 Hz
– additional conversion time for wire-break
monitoring
5 ms
• Interference voltage suppression for interfer‐
ence frequency f1 in Hz
50 / 60 Hz
Smoothing of measured values
Analog electronic modules
14.4 Analog electronics module 4 AI RTD
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 359
