Siemens SIMATIC ET 200iSP User Manual

Technical speci󹪝cations
• Thermocouple
Type E, N, J, K, L, S, R, B, T, U/ min. 1 MΩ
Connection of signal generators
• for thermal e.m.f. measurement
supported
Characteristic linearization Yes
• Thermal e.m.f. measurement
Nominal range linear
• Thermocouple
Type E, N, J, K, L, S, R, B, T, U
Temperature compensation
• Internal temperature compensation
possible via the TC sensor module supplied
• External temperature compensation
Possible via temperature value recorded at
an analog module of the same ET 200iSP
station.
Approvals
ATEX II 2 G(1) GD and I M2
Ex ib [ia Ga] IIC T4 Gb
Ex ib [ia IIIC Da] IIC T4 Gb
Ex ib [ia/] I Mb
KEMA 04 ATEX 1246
0344
IECEx IECEx KEM 05.0008
INMETRO
R
#3
0$1
BR-Ex ib [ia Ga] IIC T4 Gb
BR-Ex ib [ia IIIC Da] IIC T4 Gb
BR-Ex ib [ia] I Mb
FM Class I, Zone 1, AEx ib [ia] IIC T4;
Ex ib [ia] IIC T4
NI, Class I, DIV. 2, GP. A,B,C,D T4
AIS, Class I, DIV. 1, GP. A,B,C,D
Class II, III, GP. E,F,G
cULus
R
-*45&%&
Process Cont. Eq. for Use in HAZ.LOC.
Class I, Zone 1, AEx ib [ia] IIC T4
Ex ib [ia] IIC T4
ASSOC APP. CL. I, DIV.2, GP. A,B,C,D
PROVIDING INT. SAFE CIRCUITS FOR
CL. I, GP. A,B,C,D;
CL. II, III, GP. E,F,G
CCC Ex ib [ia Ga] IIC T4 Gb
Ex ib [iaD] IIC T4 Gb
UKCA DEKRA 21UKEX0086
Analog electronic modules
14.5 Analog electronics module 4 AI TC
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 369
