Technical speci󹪝cations
Noise suppression, error limits
Operational limit (over the entire temperature range, rel‐
ative to the input range)
2
±1.5 K
Basic error limit (operational limit at 25 °C, relative to the
input range)
2
±1 K
Linearity error (relative to the input range) ± 0.015%
Repeatability (in settled state at 25 °C, relative to input
range)
± 0.01 %
Limits of total error when using internal compensation
with TC sensor module
• Operational limit (in the entire temperature range at
static thermal state, ambient temperature change < 10
K/hour).
±3.5 K
• Basic error limit (operational limit at 25 °C at static
thermal state, ambient temperature change < 0,3 K/
min)
±2 K
Status, interrupts, diagnostics
• Group error display
Red "SF" LED
Monitoring for
• Wire break
Yes, can be set
R> 1.7 kΩ
• TC sensor module for internal temperature compensa‐
tion
Yes
Safety information
U
o
= 5.9 V
I
o
= 15 mA
P
o
= 23 mW
C
o
= 43 μF
L
o
= 100 mH
For additional C
o
/ L
o
combinations, see certi󹪝cate IECEx KEM 05.0008
https://www.iecex.com (https://www.iecex.com)
KEMA 04 ATEX1246 INMETRO UL-BR 12.0071
https://support.industry.siemens.com (https://support.industry.siemens.com)
1
Time taken to reach 63 % of the jump value
2
The speci󹪝ed error limits apply as of the following temperatures:
Thermocouple type T: -200 °C
Thermocouple type B: +700 °C
Thermocouple type N: -150 °C
Thermocouple type E: -150 °C
Thermocouple type R: +200 °C
Thermocouple type S: +100 °C
Data for selecting a sensor
Input ranges (rated values) / input resistance
• Thermoelectric voltage
±80 mV/ min. 1 MΩ
Analog electronic modules
14.5 Analog electronics module 4 AI TC
ET 200iSP
368 Operating Instructions, 11/2022, A5E00247483-AK
