Article number 6ES7134-7SD00-0AB0
• Common mode interference, min.
90 dB
Interrupts/diagnostics/status information
Alarms
• Diagnostic alarm
Yes; Parameterizable
• Limit value alarm
Yes; Parameterizable
Diagnoses
• Diagnostic information readable
Yes
Diagnostics indication LED
• Group error SF (red)
Yes
Potential separation
Potential separation analog inputs
• between the channels
Yes; Functional
• between the channels and backplane bus
Yes
Standards, approvals, certicates
CE mark Yes
Highest safety class achievable in safety mode
• Performance level according to ISO 13849-1
none
• SIL acc. to IEC 61508
No
Dimensions
Width 30 mm
Height 129 mm
Depth 136.5 mm
Weights
Weight, approx. 230 g
Technical specications
Approvals
Voltages, currents, electrical potentials
Electrical isolation
• Between channels and power bus
Yes
Formation of analog values
Measuring principle Integrating (sigma-delta)
Integration/conversion time/resolution (per channel)
• Integration time can be congured
Yes
• Interference frequency suppression in Hz
60; 50
• Basic conversion time including integration time (per
channel) in ms
66; 80
• Additional conversion time for wire-break check in ms
5
• Cycle time in ms
Number of active channels per module x
basic conversion time
• Resolution (including overrange)
15 bits + sign
Analog electronic modules
14.5 Analog electronics module 4 AI TC
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 367
