Parameters for con󹪝guration "4 AI I 2WIRE HART", "4 AI I 4WIRE HART"
Table 14-39 Parameters for con󹪝guration "4 AI I 2WIRE HART", "4 AI I 4WIRE HART"
Parameter Range of values Default Applicability
4 AI I 2WIRE HART 4 AI I 4WIRE HART
Hardware interrupt (on limit violation)
• Enabled
• Disabled
Disabled Channel
Measuring range ---
• Disabled
• 4 to 20 mA
• HART
HART Channel
--- Measuring range
• Disabled
• 0 to 20 mA
• 4 to 20 mA
• HART
HART Channel
Group diagnostics
• Enabled
• Disabled
Enabled Module
Over󹪞ow/under󹪞ow diagnostics
• Enabled
• Disabled
Enabled Module
Smoothing
• None
• Low
• Average
• Strong
None Channel
High limit Low to high limit of the
overrange (SIMATIC S7)
High limit Channel
Low limit Low to high limit of the
overrange (SIMATIC S7)
Low limit Channel
Diagnostics: wire break
• Enabled
• Disabled
Enabled Channel
Diagnostics: short-circuit ---
• Enabled
• Disabled
Enabled Channel
Parameters for con󹪝guration "4 AI I 2W+x", "4 AI I 4W+x"
In addition to the "4 AI I 2WIRE HART" and "4 AI I 4WIRE HART" con󹪝guration, the following
parameters can be set in the "...W+x" con󹪝gurations:
Table 14-40 Parameters for con󹪝guration "...W+x"
Parameter Range of values Default Applicability
4 AI I 2WIRE HART 4 AI I 4WIRE HART
HART retries (number of retries) 0 to 10 2 Module
HART Fast Mode
• Enabled
• Disabled
Disabled Module
Analog electronic modules
14.11 Parameters of the analog electronic modules
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 401
