Parameters Range of values Default Applicability
4 AI RTD 4 AI TC
Measuring range ---
• Pt 100 standard range
• Pt 100 climatic range
• Ni 100 standard range
• Ni 100 climatic range
• 600 Ω absolute
• 1000 Ω absolute
Pt 100 standard
range
Channel
--- Measuring range
• Disabled
• ± 80 mV
• Type B [PtRh-PtRh]
• Type N [NiCrSi-NiSi]
• Type E [NiCr-CuNi]
• Type R [PtPh-Pt]
• Type S [PtPh-Pt]
• Type J [Fe-CuNi]
• Type L [Fe-CuNi]
• Type T [Cu-CuNi]
• Type K [NiCr-Ni]
• Type U [Cu-CuNi]
Type K [NiCr-Ni] Channel
Group diagnostics
• Enabled
• Disabled
Enabled Module
Diagnostics over󹪞ow/under󹪞ow
• Enabled
• Disabled
Enabled Module
Diagnostics: wire break
• Enabled
• Disabled
Enabled Channel
Diagnostics short-cir‐
cuit
2
---
• Enabled
• Disabled
Enabled Channel
--- Reference junction
• None
• Yes
• RTD
None Channel
--- Reference junction
number
• 1
• 2
• Internal
1 Channel
Smoothing
• None
• Low
• Average
• Strong
None Channel
High limit Low to high limit of the overrange
(SIMATIC S7)
High limit Channel
Analog electronic modules
14.11 Parameters of the analog electronic modules
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 403
