Note
Terminal modules with blue and black terminals
Terminal modules with blue terminals and terminal modules with black terminals may not be
combined within a ET 200iSP station. Exception: TM-RM/RM, any combination is possible here.
An ET 200iSP station constructed with black terminals only, and an ET 200iSP station
constructed with blue terminals only, must not be connected to the same RS 485-IS coupler if the
station is connected to blue terminals with signal lines from the explosion-proof area.
Power supply
Table A-3 Power supply
Designation Quantity Article number
Power supply PS DC24V 1 unit 6ES7138-7EA01-0AA0
Power supply PS AC120/230V 1 unit 6ES7138-7EC00-0AA0
Digital electronic modules
Table A-4 Digital electronic modules
Designation Quantity Article number
8 DI NAMUR 1 unit 6ES7131-7RF00-0AB0
4 DO DC23.1V/20mA shut down "H" 1 unit 6ES7132-7RD01-0AB0
4 DO DC17.4V/27mA shut down "H" 1 unit 6ES7132-7RD11-0AB0
4 DO DC17.4V/40mA shut down "H" 1 unit 6ES7132-7RD22-0AB0
4 DO DC23.1V/20mA shut down "L" 1 unit 6ES7132-7GD00-0AB0
4 DO DC17.4V/27mA shut down "L" 1 unit 6ES7132-7GD10-0AB0
4 DO DC17.4V/40mA shut down "L" 1 unit 6ES7132-7GD21-0AB0
4 DO DC25.5V/22mA shut down "L" 1 unit 6ES7132-7GD30-0AB0
2 DO Relay UC60V/2A 1 unit 6ES7132-7HB00-0AB0
Analog electronic modules
Table A-5 Analog electronic modules
Designation Quantity Article number
4 AI I 2WIRE HART 1 unit 6ES7134-7TD00-0AB0
4 AI I 4WIRE HART 1 unit 6ES7134-7TD50-0AB0
4 AI RTD 1 unit 6ES7134-7SD51-0AB0
4 AI TC and TC sensor module 1 unit 6ES7134-7SD00-0AB0
4 AO I HART 1 unit 6ES7135-7TD00-0AB0
Appendix
A.1 Article numbers
ET 200iSP
420 Operating Instructions, 11/2022, A5E00247483-AK
