Rules for con󹪝guration of the ET 200iSP in Zone 22
If you use the ET 200iSP in zone 22, then you must observe the following rules:
1. Install the ET 200iSP in a metallic (see section "Installation rules (Page 101)"), dust-protected
enclosure with at least degree of protection IP5X (according to directive 2014/34/EU for
category 3D). Additional requirements (surface temperature, for example) can be found in
the certi󹪝cation document for the enclosure (see Appendix "Article numbers (Page 419)").
2. See points 2 to 5: Rules for the con󹪝guration of the ET 200iSP in Zone 1
DANGER
Conductive dust
If the Zone 22 potentially explosive area is subject to conductive dust (for example, metal
dust), the rules for zone 21 apply.
Rules for the con󹪝guration of ET 200iSP in the safe area
If you use the ET 200iSP in the safe area, then you must observe the following rules:
1. Install the ET 200iSP in an enclosure with degree of protection IP20.
2. See points 2, 4 and 5: Rules for the con󹪝guration of the ET 200iSP in Zone 1
Rules for con󹪝guring the encoders, actuators, HART 󹪝eld devices in the hazardous area
The veri󹪝cation of intrinsic safety for each 󹪝eld circuit must be made according to the regulations
stipulated by the relevant standards for con󹪝guration, selection and installation.
A simple, intrinsically safe circuit results from attaching a sensor, actuator or HART 󹪝eld device
to an input or output of the electronic modules.
Con󹪝gurations (principle)
4.4 Rules for operation in hazardous areas
ET 200iSP
68 Operating Instructions, 11/2022, A5E00247483-AK
