Siemens SIMATIC ET 200iSP

• 2 x Power Supply PS
• Interface module:
– For connection on the PROFINET IO: IM 152-1PN (V1.0 and higher):
or
– For connection on the PROFIBUS DP: IM 152-1DP (V2.0 and higher):
Combination options of the power supply PS with TM-PS-A (6ES7193-7DA10-0AA0) and TM‑PS‑B
(6ES7193-7DB10-0AA0)
TM-PS-A (6ES7193-7DA10-0AA0) TM-PS-B (6ES7193-7DB10-0AA0)
PS DC24V* PS DC24V*
* All product versions
Combination options of the power supply PS with TM-PS-A (6ES7193-7DA20-0AA0) and TM‑PS‑B
(6ES7193-7DA20-0AA0)
TM-PS-A (6ES7193-7DA20-0AA0) TM-PS-B (6ES7193-7DB20-0AA0)
PS DC24V* PS DC24V*
PS AC120/230V** PS AC120/230V**
PS DC24V* PS AC120/230V**
* Product version 7 and higher
** Maximum output current, see technical speci󹪝cations in section Power Supply PS AC120/230V
Combination options of the power supply PS with TM-PS-A (6ES7193-7DA10-0AA0) and TM‑PS‑B
(6ES7193-7DA20-0AA0) or TM‑PS‑A (6ES7193-7DA20-0AA0) and TM-PS-B (6ES7193-7DB10-0AA0)
TM-PS-A (6ES7193-7DA10-0AA0) TM-PS-B (6ES7193-7DA20-0AA0)
PS DC24V* PS AC120/230V**
TM-PS-A (6ES7193-7DA20-0AA0) TM-PS-B (6ES7193-7DB10-0AA0)
PS AC120/230V** PS DC24V*
* Product version 5 and higher
** Maximum output current, see technical speci󹪝cations in section Power Supply PS AC120/230V
Mounting and wiring
1. When installing, start with the TM-PS-A.
2. Install the TM-PS-A to the right of the TM-PS-B.
3. Complete the ET 200iSP con󹪝guration.
Con󹪝gurations (principle)
4.12 Redundancy of the Power Supply
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 83
