Siemens SIMATIC ET 200SP System Manual

Configuring
7.1 Configuring ET 200SP
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
133
Configuration of the ET 200SP
See the STEP 7 online help or the documentation of the configuration software
manufacturer.
Note
For I/O modules that are installed on a BaseUnit BU..D (lig
ht-colored BaseUnit), you always
have to set the parameter "Potential group" to "Enable new potential group". If you do not set
this parameter correctly, the CPU/interface module goes to STOP and generates a
parameter error.
Note
For PROFIBUS with configuration via GSD file
In the configuration software, you must set for the BU covers whether these are on a light
-
colored or dark
-colored BaseUnit.
Configuring F-modules with a GSD file
If you want to configure F-modules with a GSD file, you need S7-FCT in order to calculate
the F_iPar_CRC and assign the PROFIsafe addresses. Additional information can be found
on the Internet (https://support.industry.siemens.com/cs/ww/en/view/109763833
).
You can find S7-FCT on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/109762827
).

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
