Technical specifications
14.5 Mechanical and climatic environmental conditions
Distributed I/O system
System Manual, 09/2019, A5E03576849-AJ
283
Tests of mechanical environmental conditions
The following table provides important information with respect to the type and scope of the
tests of environmental mechanical conditions.
Table 14- 9 Tests of mechanical environmental conditions
Condition tested
Test standard
Comment
Vibrations
2)
Vibration test accord-
ing to IEC 60068-2-6
(sinusoidal)
Type of vibration: Frequency sweeps with a rate of change of 1 oc-
tave/minute.
BA 2×RJ45, BA SCRJ/RJ45, BA LC/RJ45, IM 155-6 PN BA, digital output
module F-RQ 1x24VDC/24..230VAC/5A
• 5 Hz ≤ f ≤ 8.4 Hz, 3.5 mm constant amplitude
• 8.4 Hz ≤ f ≤ 150 Hz, 1 g constant acceleration
IM 155-6 DP HF, BA 2×FC, BA 2xSCRJ, BA SCRJ/FC, BA 2xLC, BA
LC/FC
• 10 Hz ≤ f ≤ 60 Hz, 0.35 mm constant amplitude
• 60 Hz ≤ f ≤ 1000 Hz, 5 g constant acceleration
Duration of vibration: 10 frequency sweeps per axis at each of three verti-
cally aligned axes
Shock
2)
Shock, tested accord-
ing to IEC 60068-2-27
Type of shock: Half-sine
Shock intensity: 150 m/s
2
peak value, 11 ms duration
Direction of shock: 3 shocks in each direction (+/-) at each of three verti-
cally aligned axes
Repetitive shock
1) 2)
Shock, tested accord-
ing to IEC 60068-2-27
Type of shock: Half-sine
Shock intensity: 25 g peak value, 6 ms duration
Direction of shock: 1000 shocks in each direction (+/-) at each of three
vertically aligned axes
1)
Not applicable in the case of the digital output module F-RQ 1x24VDC/24..230VAC/5A
2)
Not applicable for motor starters
