Output Parameters
Parameter Data Type Default setting Meaning WinCC Tag
COOL_T WORD 16#0 cooling time in [s] Y
COUNT1 WORD 16#0 counter 1 N
COUNT2 WORD 16#0 counter 2 N
CS_0 BYTE 16#0 control/signal data
(record 130) byte 0
N
CS_1 BYTE 16#0 control/signal data
(record 130) byte 1
N
CS_2 BYTE 16#0 control/signal data
(record 130) byte 2
N
CS_3 BYTE 16#0 control/signal data
(record 130) byte 3
N
CS_4 BYTE 16#0 control/signal data
(record 130) byte 4
N
CS_5 BYTE 16#0 control/signal data
(record 130) byte 5
N
CS_6 BYTE 16#0 control/signal data
(record 130) byte 6
N
CS_7 BYTE 16#0 control/signal data
(record 130) byte 7
N
CS_8 BYTE 16#0 control/signal data
(record 130) byte 8
N
CS_9 BYTE 16#0 control/signal data
(record 130) byte 9
N
CUR REAL 0 motor current in
%Ie
Y
CUR_QC BYTE 16#80 Quality Code for
Cur
N
LOCKED BOOL FALSE 1=SIMOCODE -
LOCKED
Y
MSG_ACK WORD 16#0 Message:
ACK_STATE output
N
MSG_ACK2 WORD 16#0 Message2:
ACK_STATE output
N
MSG_STAT WORD 16#0 Message: STATUS
Output
N
MSG_STAT2 WORD 16#0 Message2: STA‐
TUS Output
N
N_OVL WORD 16#0 number of over‐
load trips
Y
N_STRT DWORD 16#0 number of starts Y
OBT2_01 WORD 16#0 process value DP
0.0-1.7 basic type
2
N
OBT2_23 WORD 16#0 process value DP
2.0-3.7 basic type
2
N
Parameter
A.2Block Parameter Of SIMO_CHN
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
92 Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003
