Siemens SIMOCODE DP User Manual

Parameter Data Type Default setting Meaning WinCC Tag
OPH WORD 16#0 operating hours in
[h] modulo 10
Y
Q1_2 BOOL FALSE SIMOCODE DP 1.2:
POS: status posi‐
tioner run open;
otherwise: not
used
Y
Q1_3 BOOL FALSE SIMOCODE DP 1.3:
POS: status posi‐
tioner drive
closed; otherwise:
not used
Y
Q1_4 BOOL FALSE SIMOCODE DP 1.4:
not used
N
Q1_5 BOOL FALSE SIMOCODE DP 1.5:
not used
N
Q1_6 BOOL FALSE SIMOCODE DP 1.6:
not used
N
Q1_7 BOOL FALSE SIMOCODE DP 1.7:
not used
N
QADD_F1 BOOL FALSE 1=additional func‐
tion 1 active
Y
QADD_F2 BOOL FALSE 1=additional func‐
tion 2 active
Y
QADDF1OP BOOL FALSE 1=operator ena‐
bled for input ADD
F1
Y
QADDF2OP BOOL FALSE 1=operator ena‐
bled for input ADD
F2
Y
QAUTOP BOOL FALSE 1=operator ena‐
bled for input AU‐
TO
Y
QBAD BOOL FALSE 1=invalid process
value
N
QCSF BOOL FALSE Control System
Fault: 1=External
Error
Y
QCST BOOL FALSE SIMOCODE DP 1.0:
Test (CST)
Y
QCTA BOOL FALSE SIMOCODE DP 1.1:
cooling time ac‐
tive
Y
QCUR BOOL FALSE motor current is
󹪞owing
Y
QCUR_AH BOOL FALSE 1=current high
limit alarm
reached
N
QCUR_AL BOOL FALSE 1=current low lim‐
it alarm reached
N
Parameter
A.2Block Parameter Of SIMO_CHN
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 93
