Parameter Data Type Default setting Meaning WinCC Tag
QMANLOP BOOL FALSE 1=operator ena‐
bled for input
MANUAL LINKED/
MANUAL OP
Y
QMANOP BOOL FALSE 1=operator ena‐
bled for input
MANUAL
Y
QMON_ERR BOOL FALSE 1=Monitoring Er‐
ror
Y
QMONITOR BOOL TRUE 1=Monitoring ac‐
tive
Y
QMSG_ERR BOOL FALSE 1=Message ERROR N
QMSG_ERR2 BOOL FALSE 1=Message2 ER‐
ROR
N
QMSG_SUP BOOL FALSE 1=Message Sup‐
pression Active
Y
QOFF BOOL FALSE SIMOCODE DP 0.1:
status OFF
Y
QOFFOP BOOL FALSE 1=operator ena‐
bled for input OFF
Y
QON1 BOOL FALSE SIMOCODE DP 0.0:
status ON1
Y
QON1OP BOOL FALSE 1=operator ena‐
bled for input ON1
Y
QON2 BOOL FALSE SIMOCODE DP 0.2:
status ON2
Y
QON2OP BOOL FALSE 1=operator ena‐
bled for input ON2
Y
QOVL BOOL FALSE SIMOCODE DP 0.3:
status overload
warning
Y
QREMOTE BOOL FALSE SIMOCODE DP 0.5:
1=REMOTE; 0=LO‐
CAL SIMOCODE
Y
QSIM BOOL FALSE 1=Simulation ac‐
tive
Y
RESOUT1 BOOL FALSE Reserved N
RESOUT2 WORD 16#0 Reserved N
RESOUT3 INT 0 Reserved N
SENSOR WORD 16#0 sensor value in
Ohm
Y
SETEXTMSG BOOL FALSE 1=Set external
Message
N
SIMO_OVL BOOL FALSE SIMOCODE Func‐
tion: 1=OVL
Y
SIMO_STAT INT 0 Status SIMOCODE Y
TRIP_CUR WORD 16#0 tripping current in
%Is
Y
Parameter
A.2Block Parameter Of SIMO_CHN
SIMOCODE DP PCS 7 Library Migration (Legacy) - V9.1 SP2
Programming and Operating Manual, 11/2022, A5E51265657002A/RS-AC/003 95
