Parameters
4.2 Motor control
SIMOCODE pro - Parameterize
106 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
You will find detailed explanations of the settings in Chapter Application selection, settings
and definitions of control functions (Page 66).
Table 4- 20 Solenoid valve control function settings
OFF Control command OFF (CLOSED) (connection with any socket, usually with
"Enabled control command OFF" socket)
ОN > Control command ON (OPEN) (connection with any socket, usually with socket
"Enabled control command - ON >")
Non-maintained command mode
• Deactivated (default setting)
• Activated
Separate fail-safe function from
control function
• Deactivated (default setting): A safety-related tripping by the DM-F modules is
also effected by the SIMOCODE pro control function, avoiding additional follow-
on fault messages. This setting is selected for applications where safety-related
tripping directly affects the motor controlled by SIMOCODE pro.
• Activated: A safety-related tripping by the DM-F modules does not affect the
SIMOCODE pro control function. This setting is selected for applications where
safety-related tripping does not affect the motor controlled by SIMOCODE pro.
Execution time Time until the end position is reached.
Range 0 to 6553.5 s (default: 1.0 s)
