Siemens SIMOCODE pro Operating Manual

Parameters
4.5 Inputs
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
181
4.5
Inputs
4.5.1
Overview of inputs
Description
SIMOCODE pro has various inputs. These are represented by different function blocks in
SIMOCODE pro. These function blocks are the ingoing SIMOCODE pro interfaces. Within
SIMOCODE pro, these inputs are represented as sockets on the corresponding function
blocks and can be assigned via connections to any functions. Inputs can be:
● Input terminals , located on the outside of the basic units and digital modules
● Buttons on operator panels (one Test / Reset button, four freely parameterizable buttons),
and basic units (one Test / Reset button)
● Temperature module inputs
● Analog module inputs
● Inputs of the communication bus

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
