4.2 Motor control
SIMOCODE pro - Parameterize
60 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
4.2.1.4
Control station settings
Table 4- 6 Control station settings
Control stations
Description
LC
Activates the control station via any signal (any sockets, but typically device inputs). The
"OFF" plug is 0-active on the control station [LC].
ON <<
ON <
OFF
ОN >
ON >>
PLC/PCS
Activates the control station via any signal (any sockets, but typically control bits from the
bus).
ON <<
ON <
OFF
ОN >
ON >>
PC
Activates the control stations via any signal (any sockets, but typically control bits from the
bus).
ON <<
ON <
OFF
ОN >
ON >>
Operator panel [OP]
Activates the control stations via any signal (any sockets, but typically buttons on the operator
panel)
<>/<<>>
ON <
OFF
ОN >
ON >>
Mode selector
For switching between the 4 operating modes Local 1, Local 2, Local 3 and remote with any
signals (any sockets, e.g. device inputs, control bits from/via the bus.).
S1
S2
