4.4 Outputs
SIMOCODE pro - Parameterize
168 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
4.4.4
Digital module outputs
Description
SIMOCODE pro has two "DM1 Outputs" and "DM2 Outputs" function blocks, which are each
equipped with two relay outputs. You can, for example, switch contactors or lamps via these
relay outputs. For this, the inputs (plugs of the "DM Outputs" function blocks) must be
connected to the respective sockets (e.g. of the control function).
Note
"DM Outputs" function blocks can only be used if the corresponding digital modules (DM) or
multifunction modules
(MM) are connected and configured in the device configuration!
Each function block has:
● Two plugs, corresponding to relay outputs Out1, Out2
● Two relays
● Output terminals.
The following are available:
● a "DM1 Outputs" function block on the pro S basic unit
1)
● two function blocks "DM1 outputs" and "DM2 outputs" on the basic units pro V.
Note
1) for the SIMOCODE
pro S basic unit, the DM1 outputs are on the multifunction module.
Note
In addition to the two jointly
-switched fail-safe enabling circuits, the fail-safe DM-F Local
and DM
-F PROFIsafe digital modules are equipped with two standard relay outputs, the
common potential of which is switched off for safety reasons via an enabling circuit.
From a logical connection point of view, the standard relay outputs are always switch
ed.
The state of the fail
-safe enabling circuits is not affected by the logical wiring.
