Parameters
4.2 Motor control
SIMOCODE pro - Parameterize
114 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
You will find detailed explanations of the settings in Application selection, settings and
definitions of control functions (Page 66).
Table 4- 23 Soft starter settings
OFF Control command OFF (connection with any socket, usually with "Enabled
control command OFF" socket)
ОN > Control command ON (connection with any socket, usually with "Enabled
control command ON >" socket)
FB ON Auxiliary control input "Feedback ON" (connection with any socket ,
usually with socket "Status - current flowing")
Non-maintained command mode
• Deactivated (default setting)
• Activated
Separate fail-safe function from control
function
• Deactivated (default setting): A safety-related tripping by the DM-F
modules also affects the SIMOCODE pro control function, avoiding
additional follow-on fault messages. This setting is selected for
applications where safety-related tripping directly affects the motor
controlled by SIMOCODE pro.
• Activated: A safety-related tripping by the DM-F modules does not affect
the SIMOCODE pro control function. This setting is selected for
applications where safety-related tripping does not affect the motor
controlled by SIMOCODE pro.
Load type You can choose between:
• Motor (default)
• Resistive load (see Chapter Application selection, settings and definitions
of control functions (Page 66))
Range 0 to 25.5 s (default: 0.5 s)
Execution time At least ≥ soft run-down time
Range 0 to 6553.5 s (default: 1.0 s)
