Parameters
4.3 Monitoring functions
SIMOCODE pro - Parameterize
146 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
Trip level, warning level
With active power monitoring, you can parameterize two different response levels (trip level /
warning level) for the upper and lower limits.
P> (upper limit)
P < (lower limit)
to 4294967.295 kW (default: 0.000 kW)
P> (upper limit)
P < (lower limit)
to 4294967.295 kW (default: 0.000 kW)
Active status of trip and warning levels
The trip level / warning level is active only when the motor is running, the startup procedure
has been completed and there is no test position feedback (TPF) (run+).
Response to trip level P> (upper limit), P< (lower limit)
Here, you can define the response of SIMOCODE pro in the event that the monitored
variable overshoots/undershoots the set trip level:
For further information, see also "Tables of responses of SIMOCODE pro" in Chapter
Important information (Page 7).
Table 4- 42 "Trip level" response for active power monitoring
0 to 25.5 s (default: 0.5 s)
Response to warning level P> (upper limit), P< (lower limit)
Here, you can define the response of SIMOCODE pro in the event that the monitored
variable overshoots/undershoots the set warning level:
For further information, see also "Tables of responses of SIMOCODE pro" in Chapter
Important information (Page 7).
Table 4- 43 "Warning level" response for active power monitoring
0 to 25.5 s (default: 0.5 s)
