Parameters
4.4 Outputs
SIMOCODE pro - Parameterize
164 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
● Activation of the main contactor in the motor feeder: You can, for example, define which
relay output is used for activating the motor contactor in the motor feeder. To do this,
connect the desired relay output to the respective "QE..." contactor activation of the
control function.
● Activation of lamps for displaying operating states: You can define, for example, which
relay outputs are to be used for controlling the lamps / LEDs that display the operating
states of the motor (Fault, ON, OFF, FAST, SLOW...). To do this, connect the desired
relay output to the respective "QE..." contactor activation of the control function. These
are provided specially for activating lamps and LEDs. In addition to the status signals, the
"QL..." lamp controls automatically signal the following using a 2-Hz flashing frequency:
– Test mode (QLE... / QLA lamp outputs are flashing)
– Unacknowledged fault (lamp output general fault QLS is flashing)
– Transfer of any other information, status information, warnings, faults, etc. to the relay
outputs.
– Lamp test: All QL outputs are activated for approx. 2 s.
In most cases, the outputs of the basic unit will be connected to the QE or QL outputs. By
referring to Table "Active control stations, contactor controls, lamp controls and status
information for the control functions," you can determine which QE outputs are required for
which control function.
Table 4- 51 Basic unit output settings
Outputs 1 to 3
Control of the "BU Outputs" function block via any signal (any socket ,
e.g. device inputs, PROFIBUS DP control bits, etc.), usually from the QE
Defaults depend on the selected application (template): See Application selection, settings
and definitions of control functions (Page 66).
