Siemens SIMOCODE pro Operating Manual

Parameters
4.5 Inputs
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
185
Application examples
The inputs can be used, for example, for connecting the start and stop buttons of the local
control station, which can then be assigned to the "Local Control Station" function block.
If assigned accordingly, the input signals can also be used to activate function blocks such
as "Reset" or "External Fault."
Power supply to the inputs
See Chapter "Wiring basic units, expansion modules and the decoupling module" in
the SIMOCODE pro system manual.
Settings
Table 4- 59 "Basic unit inputs" settings
Inputs
Description
Debounce time You can set a debounce time for the inputs, if required. Range: 6, 16, 26, 36 ms
(default: 16 ms)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
