Parameters
4.5 Inputs
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
193
Among other things, you can monitor the following motor components:
● Motor windings
● Motor bearings
● Motor coolant temperature
● Motor gearbox oil temperature
The individual temperatures of the three sensor measuring circuits can be monitored
independently of each other by connecting free limit monitors.
Table 4- 63 Temperature module input settings
PT100 (default), PT1000, KTY83, KTY84, NTC
Response
1)
to sensor fault/out of range Disabled, signal, warn (default), tripping
1 sensor, 2 sensors, 3 sensors (default)
1) see Table "Sensor fault / Out of range response"
Table 4- 64 "Sensor fault / Out of range" response
Sensor fault/Out of range
signaling X
See also "Tables of responses of SIMOCODE pro" in Chapter Important information
(Page 7).
