Siemens SIMOCODE pro Operating Manual

Parameters
4.5 Inputs
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
195
Application examples
Typical applications are:
● Fill-level monitoring for implementing dry running protection for pumps
● Monitoring of pollution in a filter using a differential pressure transducer.
Settings
Table 4- 65 Analog module input settings
Analog module
Description
Input signal
0 to 20mA (default), 4 to 20 mA
Response to open circuit Signal, warn (default), tripping
Active inputs
1 input (default), 2 inputs
Notes
Note
The value of the analog module inputs is in S7 format.
Note
The inputs of the analog module are passive inputs, i.e. to configure an analog input circuit,
each input will require an additional, isolated external current source connected in series. If
the output of the analog module is not being used by another application, it can also be used
as a current source for an analog module input circuit. The "Start value of value range" and
the "End value of value range" of the analog module output have to be set to 65535 for this.
Thus, the maximum possible current will a
lways be available via the analog module output.

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
