Parameters
4.7 Standard functions
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
211
Special reset options:
A specific reset input is also available in addition to the other reset options (remote reset,
Test / Reset buttons, OFF command reset). Furthermore, Auto-Reset can also be activated.
See table below.
Settings
Table 4- 72 "External Fault" settings
External fault 1 to 6
Description
Input Activation of the "External Fault" function block by the monitored signal (any sockets, e.g. device
inputs, communication bus control bits, etc.)
Type Specification of the input logic:
• NO contact (1-active) (default)
• NC contact (0-active)
Active status Specify in which motor operating state the external fault is to be evaluated:
• Always (default): Always evaluate, regardless of whether the motor is running or at a standstill
• Only when motor on: Evaluation only if motor is switched ON.
Response Specification of the response to an external fault when activated via the input (see the following
table and Chapter Important information (Page 7)).
Reset Acknowledge the "External fault" fault via any signal (any sockets, e.g. device inputs,
communication bus control bits, etc.)
Reset also by Specification of further (common) acknowledgement options using additional reset types:
• Test/Reset buttons on the basic unit and the operator panel or, in the case of the operator
panel with display, via the menu (panel reset) (default)
• Remote reset: Acknowledgment via reset 1 to 3, DPV1, "Reset" command (default)
• Auto reset: The fault resets itself after the cause has been eliminated (after removal of the
activation signal)
• OFF command reset: "OFF" control command, resets the fault
Marking
1)
No parameters. Optional marking for designating the event, e.g. "Speed >," e.g. with
SIMOCODE ES. Range: maximum 10 characters.
Note
Changing the marking of all Ethernet and PROFINET connections
Each change to the marking requires that the communication interface be restarted when the
web server is active.
A new start interrupts all Ethernet and PROFINET links and reestablishes them afterward.
