Siemens SIMOCODE pro Operating Manual

Parameters
4.8 Logic modules
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
257
Schematic
The following schematic shows the "Limit monitor" logic modules:
Figure 4-105 "Limit Monitor" logic modules
Response
Table 4- 96 Limit monitor response
Response
Limits 1 to 6
tripping
—
warn
—
signaling
X (d)
disabled
—
delay
0 to 25.5 s (default: 0.5 s)
See also "Tables of responses of SIMOCODE pro" in Chapter Important information
(Page 7).

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
