Page #259 background image
Parameters
4.8 Logic modules
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
259
Settings
Table 4- 97 Limit monitor settings
Limit monitor
Description
Input Analog plug of the limit monitor for linking to the analog value to be monitored (2 bytes), e.g.
maximum current I_max, remaining cooling down period, actual value of timers, etc.
Type Specifies if the limit has to be monitored for overshooting (default) or undershooting.
Active status Determines in which motor operating state the limit monitor is to be evaluated:
ON, i.e. always (default) evaluate, regardless of whether or not the motor is running
ON+, i.e. always evaluate, regardless of whether or not the motor is running Exception: "TPF", i.e.
motor feeder is in test position
RUN, i.e. evaluate only if the motor is in the ON state and not in the test position (TPF).
RUN+, i.e. evaluate only if the motor is running and the startup procedure is finished (i.e. the
"Start active" message is no longer active) and there is no test position feedback (TPF); example:
Cos phi monitoring
Limit Monitor response value. The return value is always determined by the "Limit monitor - Delay"
parameter.
Range: 0 to 65535 (default: 0)
delay Specifies the time period for which the limit must be constantly overshot before the "Event - Limit"
output is set.
Range: 0 to 25.5 s (default: 0.5 s)
Marking
1)
No parameters. Optional marking for identifying the message, e.g. "Limit>"; range: max. 10
characters.
NOTICE
Changing the marking (PROFINET)
Each change to the marking requires that the communication interface be restarted when
the web server is active. A new start interrupts all Ethernet and PROFINET links and
reestablishes them afterward.
Note
When using limit monitors, always ensure that the correct range and unit are used for the
analog values
connected to the limit input. These always have a direct influence on the unit
of the limit value to be set. The units and ranges of all relevant analog values can be found in
"Data record 94
- Measured values" and "Data record 95 - Service data/statistical data" in
the "SIMOCODE
pro - Communication, tables, data records" manual.
