Parameters
4.1 Motor protection
SIMOCODE pro - Parameterize
36 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
Transformation ratio - active
When using an interposing transformer, or if the main supply cable is looped several times
through the current measuring module or the current / voltage measuring module, you can
enter the transformation ratio.
Activate the checkbox if you wish to use this option. The parameterized current setting
continues to correspond here to the actual rated motor current and does not have to be
converted.
The transformation ratio is calculated from the ratio between the rated motor current [A] and
the measured current [A] or any multiple of the ratio.
Note
This parameter is only available when using SIMOCODE pro V
PB above version *E03*.
Transformation ratio - primary
Enter the primary current here, with the "Transformation ratio - active" checkbox activated.
Range: 0 to 8191.875 (default: 0).
Transformation ratio - secondary
Enter the secondary current here, with the "Transformation ratio - active" checkbox
activated. Range: 0 to 15 (default: 0).
Note
In the case of motors with two speeds, the same or different transformation ratios can be set
for each speed, depending upon whether the same or two different interposing transformers
is/are used for each speed.

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
