Parameters
4.2 Motor control
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
75
You will find detailed explanations of the settings in Chapter Application selection, settings
and definitions of control functions (Page 66).
Table 4- 11 Direct starter settings
Direct starter (direct-on-line starter)
OFF
Control command OFF
Connection with any socket, usually with "Enabled control command OFF" socket
ON >
Control command ON
Connection with any socket, usually with "Enabled control command - ON >" socket
FB ON
"Feedback ON" auxiliary control input
Connection with any socket, usually with "Status - current flowing" socket
Non-maintained command mode
• Deactivated (default setting)
• Activated
Separate fail-safe function from
control function
• Deactivated (default setting): A safety-related tripping by the DM-F modules
also affects the SIMOCODE pro control function, avoiding additional follow-on
fault messages. This setting is selected for applications where safety-related
tripping directly affects the motor controlled by SIMOCODE pro.
• Activated: A safety-related tripping by the DM-F modules does not affect the
SIMOCODE pro control function. This setting is selected for applications where
safety-related tripping does not affect the motor controlled by SIMOCODE pro.
Load type You can choose between:
• Motor (default)
• Resistive load (see Chapter Application selection, settings and definitions of
control functions (Page 66))
Range 0 to 25.5 s (default: 0.5 s)
Range 0 to 6553.5 s (default: 1.0 s)
