4.2 Motor control
SIMOCODE pro - Parameterize
78 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
Settings
You will find detailed explanations of the settings in Chapter Application selection, settings
and definitions of control functions (Page 66).
Table 4- 12 Reversing starter settings
Reversing starter
Description
ON < Control command ON <, counter-clockwise
Connection with any socket, usually with "Enabled control command - ON <" socket
OFF Control command OFF
Connection with any socket, usually with "Enabled control command OFF" socket
ON > Control command ON >, clockwise
Connection with any socket, usually with "Enabled control command - ON >" socket
FB ON "Feedback ON" auxiliary control input
Connection with any socket, usually with "Status - current flowing" socket
Non-maintained command mode
• Deactivated (default setting)
• Activated
Saving change-over command
• Deactivated (default setting)
• Activated
Separate fail-safe function from
control function
• Deactivated (default setting): A safety-related tripping by the DM-F modules also
affects the SIMOCODE pro control function, avoiding additional follow-on fault
messages. This setting is selected for applications where safety-related tripping
directly affects the motor controlled by SIMOCODE pro.
• Activated: A safety-related tripping by the DM-F modules does not affect the
SIMOCODE pro control function. This setting is selected for applications where
safety-related tripping does not affect the motor controlled by SIMOCODE pro.
Load type You can choose between:
• Motor (default)
• Resistive load (see Chapter Application selection, settings and definitions of control
functions (Page 66))
Feedback time
Range 0 to 25.5 s (default: 0.5 s)
Execution time
Range 0 to 6553.5 s (default: 1.0 s)
Interlocking time
Range 0 to 255 s (default: 0 s)
