Parameters
4.2 Motor control
SIMOCODE pro - Parameterize
Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
81
You will find detailed explanations of the settings in Chapter Application selection, settings
and definitions of control functions (Page 66).
Table 4- 13 Circuit breaker settings
OFF Control command OFF
(Connection with any socket, usually with "Enabled control command OFF" socket)
ОN > Control command ON
(Connection with any socket, usually with "Enabled control command ON >" socket)
FB ON Auxiliary control input "Feedback ON" (connection always with socket, (input), that
the auxiliary switch of the circuit breaker is connected to).
Non-maintained command mode
• Deactivated (default setting)
• Activated
Separate fail-safe function from
control function
• Deactivated (default setting): A safety-related tripping by the DM-F modules also
affects the SIMOCODE pro control function, avoiding additional follow-on fault
messages. This setting is selected for applications where safety-related tripping
directly affects the motor controlled by SIMOCODE pro.
• Activated: A safety-related tripping by the DM-F modules does not affect the
SIMOCODE pro control function. This setting is selected for applications where
safety-related tripping does not affect the motor controlled by SIMOCODE pro.
Load type You can choose between:
• Motor (default)
• Resistive load (see Chapter Application selection, settings and definitions of
control functions (Page 66))
Feedback time A repeated ON pulse is only output by the QE1 contactor control once the set
feedback time has elapsed. The feedback time should therefore be set higher than
the motor off time of the motorized operating mechanism of the circuit breaker.
Range 0 to 25.5 s (default: 0.5 s)
Range 0 to 6553.5 s (default: 1.0 s)
