Parameters
4.2 Motor control
SIMOCODE pro - Parameterize
92 Operating Manual, 04/2017, A5E40507630002A/RS-AA/001
You will find detailed explanations of the settings in Chapter Application selection, settings
and definitions of control functions (Page 66).
Table 4- 16 Dahlander settings
OFF Control command OFF
Connection with any socket, usually with "Enabled control command OFF" socket
ОN > Control command ON > (SLOW)
Connection with any socket, usually with "Enabled control command ON >" socket
ON >> Control command ON >> (FAST)
Connection with any socket, usually with "Enabled control command ON >>" socket
FB ON "Feedback ON" auxiliary control input
Connection with any socket, usually with "Status - current flowing" socket
Non-maintained command mode
• Deactivated (default setting)
• Activated
Separate fail-safe function from
control function
• Deactivated (default setting):
• A safety-related tripping by the DM-F modules also affects the SIMOCODE pro
control function, avoiding additional follow-on fault messages. This setting is
selected for applications where safety-related tripping directly affects the motor
controlled by SIMOCODE pro.
• Activated: A safety-related tripping by the DM-F modules does not affect the
SIMOCODE pro control function. This setting is selected for applications where
safety-related tripping does not affect the motor controlled by SIMOCODE pro.
Saving change-over command
• Deactivated (default setting)
• Activated
Load type You can choose between:
• Motor (default)
• Resistive load (see Chapter Application selection, settings and definitions of control
functions (Page 66))
Range 0 to 25.5 s (default: 0.5 s)
Range 0 to 6553.5 s (default: 1.0 s)
Range 0 to 655.3 s (10 ms steps) (default: 0.00 s)
