Siemens SINAMICS S110 User Manual

Cabinet design and EMC for components, Blocksize format
10.5 24 V DC Supply Voltage
SINAMICS S110
236 Manual, 07/2015, 6SL3097-4AC10-0BP5
Component
Typical current consumption [A
DC
]
Sensor Module External
SME20
without/with encoder system 0.15 / 0.25
SME25
without/with encoder system
0.15 / 0.25
SME120
without/with encoder system
0.20 / 0.30
SME125
without/with encoder system
0.20 / 0.30
10.5.5
Selecting power supply units
You are advised to use the devices in the following table. These devices meet the applicable
requirements of EN 60204-1.
Table 10- 4 Recommended SITOP Power
Rated output cur-
rent [A]
Phases
Rated input voltage [V]
Operating voltage range [V]
Short-circuit current [A]
Article No.
5 1 / 2 AC 120 … 230 / 230 … 500
85 … 264 / 176 … 550
Approx. 5.5 (power up)
Typ. 15 for 25 ms (opera-
tion)
6EP1333-3BA00-8AC0
10 1 / 2 AC 120 … 230 / 230 … 500
85 … 264 / 176 … 550
Approx. 12 (power up)
Typ. 30 for 25 ms (opera-
tion)
6EP1334-3BA00-8AB0
20 1 / 2 AC 120 / 230
85 … 132 / 176 … 264
Approx. 23 (power up)
Typ. 60 for 25 ms (opera-
tion)
6EP1336-3BA00-8AA0
3 3 AC 230 / 400 … 288 / 500
320 … 550
6EP1436-3BA00-8AA0
40 1 / 2 AC 120 / 230
85 … 132 / 176 … 264
Approx. 46 (power up)
Typ. 120 for 25 ms (opera-
tion)
6EP1337-3BA00-8AA0
3 3 AC 230 / 400 … 288 / 500
320 … 550
6EP1437-3BA00-8AA0
Table 10- 5 Recommendation for Control Supply Module
Rated output cur-
rent [A]
Phases
Input voltage range [V]
Short-circuit current [A]
Article No.
20 3 3-phase 380 V AC -10 % (-15 %
< 1 min) to 480 V AC +10%
DC 300 … 800
< 24 6SL3100-1DE22-0AAx
You will find more information on power supply units in catalogs PM21 and NC61.
