Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
01/2017
157
Signal
Description
Remark
I4.2
Handheld unit: axis Z selected
Valid at a high level
I4.3
Handheld unit: fourth axis selected
Reserved
I4.4
Handheld unit: increment X1
Valid at a high level
I4.5
Handheld unit: increment X10
Valid at a high level
I4.6
Handheld unit: increment X100
Valid at a high level
I4.7
Handheld unit: enabled
Valid at a high level
Q0.0
Working lamp
Q0.1
-
Q0.2
Tailstock forward
Q0.3
Tailstock backward
Q0.4
Cooling pump
Q0.5
Lubrication pump
Q0.6
Chuck output 1
Q0.7
Chuck output 2
Q1.0
Turret motor rotating clockwise
Q1.1 Turret motor rotating counter-clockwise
Q1.2
Reserved for other types of turrets
Q1.3
Reserved for other types of turrets
Q1.4 Gear shift: low gear level (SBR49: GearChg1_Auto) / Gear level status
(SBR50: GearChg2_Virtual)
Q1.5
Gear shift: high gear level (SBR49: GearChg1_Auto)
Q1.6
-
Q1.7
Handheld unit valid
Definition of user-defined keys on the MCP
User-defined key 1 Working lamp
User-defined key 2
Manual cooling
User-defined key 3
Manual tool change
User-defined key 4
Manual chuck clamping and unclamping
User-defined key 5
Chuck clamping internally/externally
User-defined key 6
Tailstock
Structure of the sample application (OB1)
Call Conditions
Subroutine Name
Description
Each scan (SM0.0)
AUX_MCP (SBR20)
Auxiliary function
Each scan (SM0.0)
AUX_3Color_LAMP (SBR24)
Three-color lamp control
First scan (SM0.1)
PLC_INI (SBR32)
PLC initialization
Each scan (SM0.0)
EMG_STOP (SBR33)
Emergency Stop control
Each scan (SM0.0) MCP_NCK (SBR37) Transferring MCP and HMI signals to
the NCK interface
Each scan (SM0.0) HANDWHL (SBR39) Selecting a handwheel through the
interface signal DB1900.DBB1xxx
Each scan (SM0.0) AXIS_CTL (SBR40) Coordinate enabling control, hardware
limit, etc.
Each scan (SM0.0)
MINI_HHU (SBR41)
Handwheel on hand-held unit
Each scan (SM0.0) SPINDLE (SBR42) Spindle control
Each scan (SM0.0)
COOLING (SBR44)
Cooling control
