Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
01/2017
453
17.10.3
Signals from axis/spindle
General signals from axis/spindle
DB3900 ...
3903
Signals from axis/spindle [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Position reached Referenced Encoder limit freq. ex-
ceeded
Spindle/no
axis
With exact/
stop, fine
With exact
stop,
coarse
Synchro-
nized 2
Synchro-
nized 1
2 1
1 Current
controller
active
Speed
controller
active
Position
controller
active
Axis/spindle
stationary
(n < n
mm
)
Follow up
mode ac-
tive
Axis ready
for opera-
tion
Traversing
requests
2 Force fixed
stop limited
Fixed stop
reached
Activate
travel to
fixed stop
Measure-
ment active
Handwheel
override
active
3 AxStop
active
4 Travel command Travel request Handwheel active (bit/binary coded)
Plus
Minus
Plus
Minus
2
1
5
Active machine function
Continuous
Var. INC
10000 INC
1000 INC
100 INC
10 INC
1 INC
6
7 Contour-
handwheel
direction of
rotation
inverted
8
9
10
11
POS_RESTO
RED 2
RED 1
Signals from axis
DB3900 ...
3903
Signals from axis [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000
Module limit
enabled
active
1001
1002 Rotary axis
in position
Indexing
axis in
position
Positioning
axis
Path axis Lubrication
pulse
1003
