Siemens SINUMERIK 808D ADVANCED

Commissioning Manual
440 01/2017
5004 ...
5007
T-number for tool measurement in JOG (DINT)
5008 ...
5011
5012 ...
5015
5016 ...
5019
17.7
Auxiliary functions transfer from NC channel
17.7.1
Overview
DB2500
Auxiliary functions from NCK channel [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
1
2
3
4 M fct. 5
change
M fct. 4
change
M fct. 3
change
M fct. 2
change
M fct. 1
change
5
6 S fct. 1
change
7
8 T fct. 1
change
9
10 D fct.
Change
11
12 H fct. 3
change
H fct. 2
change
H fct.
change
13
14
15
16
17
18
19
