Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
444 01/2017
6
Value from PLC for digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Hardware
output
7
Setting mask for NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Hardware
output
17.8.4
Signals from fast inputs and outputs
DB2900
Signals from fast inputs and outputs [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Actual value for digital NCK inputs
Input 8
Input 7
Input 6
Input 5
Input 4
Hardware input
4
Setpoint for digital NCK outputs
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Hardware
output
DB3000
Mode signals to NCK [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Reset Mode
change
block
Mode
JOG MDI AUTO
1
Single block
Machine function
Type A
Type B
REF
2
Machine function
1)
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
3
1)
To use the machine function signals in DB3000.DBB2, you must set the "INC inputs in the operating-mode signal range
active" signal (DB2600.DBX1.0) to "1".
DB3100
Mode signals from NCK [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Reset 808
READY
Mode
JOG
MDI
AUTO
1
Active machine function
REF
2
Machine function
Continuous
traversing
active
Var. INC
active
10000 INC
active
1000 INC
active
100 INC
active
10 INC
active
1 INC ac-
tive
3
