17.6.2
Program selection from PLC (retentive area)
DB1700
Program selection [r/w]
PLC -> HMI interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000
Program selection from the PLC: Program number
1001
Command job from the PLC: Command
1002
1003
17.6.3
Checkback signal: Program selection from HMI (retentive area)
DB1700
Program selection [r]
HMI -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
2000 Error pro-
gram selec-
tion
Program
selected
2001 Error com-
mand exe-
cution
Execute
command
2002
2003
17.6.4
Signals from HMI
DB1800
Signals from HMI [r]
HMI -> PLC interface (signals are only present for PLC cycle)
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0 Reset Start
measure-
ment in
JOG
JOG Mode MDI AUTOMATI
C
1
Active the machine function
REF
2
3
17.6.5
Signals from PLC
DB1800
Signals from PLC [r]
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000 Commis-
sioning
archive has
been read
in
Boot with
saved data
Boot with
default
values
1001
1002
1003
1004
PLC cycle in μs [DINT]
1008
Year: Tens digit, BCD
Year: Units digit, BCD
1009
Month: Tens digit, BCD
Month: Units digit, BCD
1010
Day: Tens digit, BCD
Day: Units digit, BCD
