Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
162 01/2017
USER_DATA_FLOAT
MD14514
Machine data -
Float
PLC interface
address
Unit
Range
Function
14514[0]
DB4500.DBD2000
-
-3.40e38 to 3.40e38
Tool magazine: spindle poisoning angle
14514[1] DB4500.DBD2004 - -3.40e38 to 3.40e38 Tool magazine: preparation position of Z axis for
tool change
14514[2]
DB4500.DBD2008
-
-3.40e38 to 3.40e38
Tool magazine: tool change position of Z axis
14514[3] DB4500.DBD2012 - -3.40e38 to 3.40e38 Tool magazine: velocity of Z axis, go to tool change
position
14514[4] DB4500.DBD2016 - -3.40e38 to 3.40e38 Tool magazine: velocity of Z axis, back to tool
change preparation position
6.6
PLC subroutine library
6.6.1
Overview
In order to simplify the PLC design, we provide refined PLC functions which have generality, such as initialization, machine
panel signal processing, emergency stop processing, axis enable control, hard limit, and reference point etc. By adding the
desired subroutine module to the main procedure, plus other supplementary procedures, you can complete the PLC
procedure design easily.
The PLC subroutine library consists of the following files:
● PLC project file: SAMPLE_TURN.PTP (application program as examples for a turning machine)
● PLC project file: SAMPLE_MILL.PTP (application program as examples for a milling machine)
Note
Through these examples, you can clearly realize how to create or invoke PLC subroutines. You can reorganize PLC
subroutines or modify netw
orks to realize most machine functions, test and debug subroutines of the library.
System resource
Resource
PLC system
resource
Input I0.0 to I2.7 (24 inputs on X100, X101, and X102)
I6.0 to I8.7 (48 distributed inputs on X301 and X302)
Output Q0.0 to Q1.7 (16 outputs on X200 and X201)
Q4.0 to Q5.7 (32 distributed outputs on X301 and X302)
RAM
M0.0 to M255.7 (256 bytes)
Non-volatile memory
DB1400.DBX0.0 to DB14000.DBX127.7 (128 bytes)
PLC user alarm
DB1600.DBX0.0 to DB16000.DBX15.7 (128 user alarms)
Timer
T0 to T15 (100 ms timer) T16 to T32 (10 ms timer)
Counter
C0 to C63 (64 counters)
NC resource
Parameter
MD14510(32)
Statistic INT: DB4500.DBW0 to DB4500.DBW62 (32 double words)
Parameter
MD14514(32)
Statistic HEX: DB4500.DBB1000 to DB4500.DBB1031 (32 bytes)
Parameter
MD14514(8)
Statistic REAL: DB4500.DBD2000 to DB4500.DBD2028 (8 double words)
Programming
tool resource
Subroutine (64)
SBR0 to SBR63 (64 subroutines)
Symbol table (32)
SYM1 to SYM32 (32 symbol tables)
