Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
388 01/2017
Frame size
FSB
FSC
FSD
Shock Operation Operational area: II
Ambient classification: 3M2
Peak acceleration: 5 g + 15 g
Duration: 30 ms + 11 ms
Quantity of shocks: 3
Summed shocks: 18
Cycle time: 1 s
Transport &
storage
Covered by vibration test
Vibration Operation Operational area II/3M2
10 Hz to 58 Hz: 0.075 mm deflection
58 Hz to 200 Hz: 1g vibration
Transport &
storage
5 Hz to 9 Hz: 3.5 mm deflection
9 Hz to 200 Hz: 1 g vibration
Ambient Classification: 1M2
Certification
Outline dimensions (W × H × D, mm) 100 × 180
× 220
140 × 260 × 240 190 × 350 × 185
Net weight
2.35 kg
5.05 kg
8.05 kg
8.3 kg
1)
The values here are given at rated load.
2)
The overvoltage threshold is 820 VDC; the undervoltage threshold is 320 VDC.
15.2.3
SINAMICS V60 servo drives
Order No. : 6SL3210-
5CC14-0UA0
5CC16-0UA0
5CC17-0UA0
5CC21-0UA0
General performance
Rated output current
4 A
6 A
7 A
10 A
Max. output current
8 A
12 A
14 A
20 A
Rated output power
0.8 kW
1.2 kW
1.6 kW
2.0 kW
Rated input power
0.9 kW
1.4 kW
1.9 kW
2.3 kW
Rated motor torque
4 Nm
6 Nm
7.7 Nm
10 Nm
Application field
Turning machines, milling machines, engraving, packaging, printing etc.
Configurable controller SINUMERIK 808D, SIMATIC S7-200 and SIMATIC S7-1200
Axis
Single-axis drive
Display
6-digit, 7-segment LED display, two LED status indicators
Keys on panel
4 tact switch keys
Setpoint interface
Pulse interface
