Siemens SINUMERIK 808D ADVANCED Commissioning Manual

Commissioning Manual
452 01/2017
2003
Spindle override
H
G
F
E
D
C
B
A
Signals to drive
DB3800 ...
3803
Signals to axis/spindle [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
4000 Holding
brake
4001 Pulse ena-
ble
Integrator
disable
speed con-
troller
4002
4003
Signals to technology functions
DB3800 ...
3803
Signals to axis/spindle [r/w]
PLC -> NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
5000 Torque
equalization
controller
on
5001
5002
5003 Stop
HIAxMove
Resume
DEPMCS
5004
5005
5006 (spin-
dle)
Spindle
positioning
Automatic
gear stage
change
Setpoint direction of rota-
tion
Spindle
stop
Counter-
clockwise
Clockwise
5007 (cou-
plings)
Delete
synchro-
nism over-
ride
5008 (SISI-
TECH)
5009 (SISI-
TECH)
5010
5011
